MDT Metal AICS Magazines in Various Calibers, Capacity and Type
These magazines are designed with a unique Double Stack to Single Feed (DSSF) transition design for reduced overall height compared to the industry standard.
DETAILS
MDT AICS-pattern metal magazines are manufactured from high strength steel, nitrided, and finished inside and outside with Cerakote Elite for ultimate durability, corrosion resistance, and friction reduction.
BINDER PLATE DETAILS
- The magazines with front binder plates are compatible with all rifles equipped with AICS-pattern bottom metal or chassis systems. The binder plate holds the cartridges back from the front of the magazines and guides them past the bottom of the feed ramp.
- The magazines without front binder plates are compatible with all AICS-pattern bottom metal and chassis systems, but most common actions such as Remington 700 and Savage 10/11 will require modifications to the receiver (i.e. notching out the bottom of the feed ramp) to prevent the bullet tips from catching on the bottom of the feed ramp
What is MED?
The MED or XM magazines are AICS pattern magazines but they are made specific to REM700 Medium chassis. There are only a few actions that use this length.
MED is short for “Medium” and refers to the length of the rifle action this magazine is compatible with. The majority of actions are either short or long action but there has been a growing desire for something in between.
These magazines work with the Medium, XM and XM Plus chassis and bottom metals available. They are great for people who want to run either a really long short action caliber that doesn’t fit in a short action mag, or a short long action cartridge that may have trouble feeding in a standard long action magazine.
Item Numbers:
.223 Rem:
10 Round: #104760-BLK
.308 Win / 6.5 Creedmoor:
5 Round, With Plate: #102014-BLK
5 Round, Without Plate: #102918-BLK
10 Round, With Plate: #102917-BLK
10 Round, Without Plate: #102014-BLK
12 Round, With Plate: #102922-BLK
12 Round, Without Plate: #102919-BLK
22-250 Remington:
10 Round: #107800-BLK
.30-06 Spfd:
5 Round, 3.560” Length: #103208-BLK
5 Round, 3.715” Length: #104269-BLK
.300 WSM / 6.5 PRC:
3 Round: #103133-BLK
7 Round: #104979-BLK
.300 PRC:
5 Round: #105123-BLK
.300 Win Mag:
5 Round, 3.560” Length: #102142-BLK
5 Round, 3.715” Length: #102143-BLK
5 Round, 3.850” Length: #102088-BLK
.338 Lapua Mag:
5 Round, 3.715” Length: #102144-BLK
5 Round, 3.850” Length: #102089-BLK
5 Round, 4.050” Length: #102147-BLK
6mm BR:
10 Round: #106214-BLK
12 Round: #104174-BLK
6mm ARC:
10 Round: #106223-BLK
12 Round: #105627-BLK
